✨ High-precision transparent PC car light mold engineered for automotive lighting applications requiring exceptional optical clarity and dimensional accuracy. Built with premium H13 hot work steel and DME standard mold base.
The mold features a cold runner system with sub-gate (pin-point gate) design, ensuring optimal melt flow for polycarbonate material while minimizing gate marks on visible surfaces. Ideal for headlight lenses, taillight covers, and interior lighting components.
Manufactured under ISO 9001:2015 and SGS certified quality management systems, delivering consistent part quality with 500,000+ shots mold life. Surface finish options include MT, YS, and SPI-A1 mirror polish for superior light transmission.
Technical Specifications
Mold Base Standard DME
Mold Material H13 Steel (Hot Work)
Product Material PC (Polycarbonate)
Standard / Certification DME / ISO 9001:2015
Runner System Cold Runner
Gate Type Sub Gate (Pin-point Gate)
Mold Weight 200 kg
Injection Machine 100-150 Ton
Surface Finish MT (Mold Tech), YS, SPI-A1
Optical Property Yellow Transparent / High Light Transmittance
Mold Life 500,000+ Shots
Delivery Time 35-40 Days
Packaging Wooden Cases (IPPC Standard)
✅ Certified: ISO 9001:2015 & SGS Certified | Quality Assurance for Automotive Industry
